High quality imaging with 4 MP resolution

Support Human and Vehicle Detection

Smart Hybrid Light: advanced technology with long range

Efficient H.265+ compression technology

Support on-board storage up to 512 GB (SD card slot) (Optional)

Built-in microphone for real-time audio security

Water and dust resistant (IP67)

Camera

Image Sensor1/3" Progressive Scan CMOS

Max. Resolution2560 × 1440

Min. Illumination Colour: 0.001 Lux @ (F1.0, AGC ON)

Shutter Time1/3 s to 1/100,000 s

Day & Night IR cut filter

Angle Adjustment Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360°

Lens

Lens Type Fixed focal lens, 2.8 and 4 mm optional

Focal Length & FOV

2.8 mm, horizontal FOV 115°, vertical FOV 60°, diagonal FOV 143°

4 mm, horizontal FOV 94°, vertical FOV 50°, diagonal FOV 110°

Lens MountM12

Iris Type Fixed

ApertureF1.0

DORI

DORI

2.8 mm, D: 64 m, O: 25 m, R: 12 m, I: 6 m

4 mm, D: 77 m, O: 30 m, R: 15 m, I: 7 m

Illuminator

Supplement Light Type IR, White Light

Supplement Light Range Up to 30 m

Smart Supplement Light Yes

IR Wavelength850 nm

Video

Main Stream

50 Hz:

20 fps (2560 × 1440)

25 fps (1920 × 1080, 1280 × 720)

60 Hz:

20 fps (2560 × 1440)

24 fps (1920 × 1080, 1280 × 720)

Sub-Stream

50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)

60 Hz: 24 fps (1280 × 720, 640 × 480, 640 × 360)

Video Compression

Main stream: H.265+/H.265/H.264+/H.264,

Sub-stream: H.265/H.264/MJPEG

Video Bit Rate 32 Kbps to 16 Mbps                                                                            H.264 Type Baseline Profile, Main Profile, High Profile                                          H.265 Type Main Profile
